Ty 60 P

Miniature single-pole pressure switch SPST normally closed contact (NC)

Maximum ambient temperature

T125 °C

Rated voltage current

12 A / 250 V

Field of intervention

0,5 - 5 bar

Built in accordance with the standard

EN 60730-2-6

Minimum current

200 mA std - 10 mA contatti dorati

ENEC (EN 60730) approved - cycle number

100.000 a 12 A ------200.000 a 8 A

Small home appliances
Other application areas

Dual pressure control with fixed set point - SPST Single pressure switch can be supplied with contact N.C. or N.A. Low pressure with automatic or manual reset High pressure with automatic or manual reset
