Adjustment range |
-35° C / +35° C ----0° C / 60° C ---- 0° C / 90° C ---- 30° C / 120° C |
---|---|
Maximum ambient temperature |
T90 |
Rated voltage current |
16(3) A / 250 V NC ----- 6(1) A / 250 V NO |
Differential |
2 - 5 K |
Capillary lenght |
1500 mm |
Heating systems | |
---|---|
Other application areas |
Suitable for applications where temperature control is required by remote probe. Internal adjustment device: capillary thermoregulator. Also available with 125 or 250 mm ventilated tube for hot air generators. Special version on request.
